DODGE PROMASTER 1 TON RV LITHIONICS BATTERY SYSTEM UPGRADE
Regency National Traveller Dodge Promaster RV with a Lithionics high performance lithium-ion battery installed by Pinnacle Innovations

Regency National Traveller Dodge Promaster RV with a Lithionics high performance lithium-ion battery installed by Pinnacle Innovations

This was a very challenging project in the sense that the Client wanted 640 Amp hours of capacity and the only logical place to locate the Lithionics batteries was underneath a rear sofa bed. Unfortunately this cabinet was not only very hard to access even by lifting the hinged sofa but there was barely enough space to fit the batteries. As there were already many devices bolted to the floor, Pinnacle had to design and custom fabricate steel battery racks that both raised the batteries above the devices on the floor and also secured them.

This Client also opted for the very popular GTX Series 12 Volt 320 Amp hour batteries with the built-in BMS.

Lithionics GTX 320 Amp hour high capacity deep cycle and engine starting lithium-ion battery: light weight, super safe, powerful and compact lithium ion battery

In addition, we also installed a Victron MPPT solar charge controller as well as Victron Orion DC to DC smart charger with 30 Amps of output from the engine when running.

Its really hard to tell just how little extra space there was to fit the batteries in. For the height, we only had less than 1/4" space to clear the metal underside frame of the sofa and the forward battery had less than millimeters to spare to fit in. In fact, I had to move parts of the existing circuit breaker panel to make room for the forward battery.

battery site spacer

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo - custom aluminum fabrication and aluminum welding

On this project the Client wanted the 30 Amp shore power breaker recessed. As such, I had to custom fabricate a special aluminum enclosure to permit this.

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo - custom aluminum fabrication and aluminum welding

On this project the Client wanted the 30 Amp shore power breaker recessed. As such, I had to custom fabricate a special aluminum enclosure to permit this. Shown here is the holder prior to painting.

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo - batteries installed

The two units of the Lithionics GTX Series battery model: GTX 12V320A-E2107-CS200

We also installed one of the 30 Amp output Victron Orion DC to DC Smart programmable battery chargers that provide isolated and optimal battery charging via the engine alternator.

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo - custom steel battery rack fabrication

Shown here are the custom steel battery holders that bolt to the floor and raise the batteries above other components on the floor.

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo - custom steel battery racks installed

Shown here are the custom steel battery holders (installed) that bolt to the floor and raise the batteries above other components on the floor.

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo - custom steel battery racks installed

Shown here are the custom steel battery holders (installed) that bolt to the floor and raise the batteries above other components on the floor.

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo - job completion photo

The two units of the Lithionics GTX Series battery model: GTX 12V320A-E2107-CS200.

Also shown are the new Blue Sea disconnect switches that are a part of the required wiring.

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo - job completion photo

The two units of the Lithionics GTX Series battery model: GTX 12V320A-E2107-CS200.

Also shown are the new Blue Sea disconnect switches that are a part of the required wiring.

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo while out on a Summer adventure

One of the nice photos that our Washington State, USA Client sent us after the installation on one of their Summer trips in the USA. This Client travelled from their home outside of Seattle to have Pinnacle Innovations perform the installation.

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo while out on a Summer adventure

Another nice photo that the Client sent us after the installation on one of their Summer trips.

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo while out on a Summer adventure

Another nice photo that the Client sent us after the installation on one of their Summer trips.

Dodge Promaster RV Lithionics Battery lithium-ion battery installation project photo while out on a Summer adventure

Another nice photo that the Client sent us after the installation on one of their Summer trips.

The following is the Lithionics Battery Warranty Approved Master Wiring Diagram that was used on this RV project:

Click on the image for a larger Lithionics battery wiring installation wiring diagram

Link to the GTX Series 12 Volt 320 Amp hour battery model shown in this diagram...

Please note: Internal BMS batteries are not approved for use on any Marine projects.

battery site spacer
Pinnacle Innovations/ getlithium.com Installation Warranty is a full 3 Years on Parts and Installation Materials (consumables like fuses/ circuit breakers excluded)
